Energy saving hydraulic power unit

CORE TECHNOLOGY:

MAIN ADVANTAGES:
- Significant energy saving effect: After actual application testing, the energy-saving hydraulic power unit can achieve more than 97% of motor downtime in the working state of the machining center, greatly reducing power consumption.
- Green and environmentally friendly: The motor is in a non-working state for a long time, does not consume electricity, does not generate heat, does not volatilize, and does not make noise, which effectively reduces energy consumption and environmental pollution, and achieves multiple goals of energy conservation, environmental protection, emission reduction and noise reduction.
- Extend equipment life: Since the motor does not work for a long time, wear and aging are reduced, thereby extending the service life of the entire system and reducing maintenance costs.
- Improve work efficiency: Stable pressure output ensures the continuity and accuracy of the processing process, improves product quality and production efficiency.

APPLICATION SCENARIOS:
- Machining center: In a long-running machining center, the system can significantly reduce energy consumption, especially in processes that require continuous pressure maintenance, and the energy-saving effect is particularly prominent.
- Machining production: It is suitable for various machining equipment that require long-term hydraulic pressure, such as stamping machines, injection molding machines, etc., which improves the reliability and economy of the equipment.

TECHNICAL PARAMETERS:

This energy saving hydraulic power unit achieves energy saving and environmental protection performance with its unique accumulator principle and intelligent control system. Whether it is used in machining centers or other industrial equipment that needs to maintain pressure for a long time, it can significantly reduce energy consumption, reduce noise and heat emissions, and at the same time improve the reliability and service life of the equipment, making it an ideal choice for modern industrial green production.

SPECIAL NOTES

The power unit is an S3 working system and can not operate continuously. It starts in 10 seconds and stops in 90 seconds.
Before installation, ensure that hydraulic components such as the oil cylinder, oil pipe, and joint are free of impurities.
The viscosity of hydraulic oil shall be 15 - 68st. No. 46 anti-wear hydraulic oil is recommended in summer, and No. 32 low-temperature hydraulic oil is recommended in winter.
After starting the operating system for the first time, check whether the oil in the oil tank is sufficient, generally 2 / 3 of the oil tank.
After the system is used for the first 100 hours, the hydraulic oil shall be replaced, and then the hydraulic oil shall be replaced every 3000 hours.

SPECIFICATIONS

Note: if you need system parameters such as pump, pressure, and motor power with different flow, please contact our salesman.
