Oil immersed double actina power unit

CORE ADVANTAGES:

- Compact integration: Integrate high pressure gear pump, AC oil immersed motor, valve block, cartridge valve and oil tank into one, significantly reducing space occupation and facilitating installation and maintenance.
- Low noise design: The optimized internal structure and efficient motor design make the noise extremely low during operation, which is suitable for noise sensitive working environment.
- High reliability: Oil immersed motor and waterproof IP68 grade design ensure long-term stable operation of the equipment in humid or underwater environment.
- Intelligent reversing control: The reversing of the oil cylinder is realized by solenoid valve, which is easy to operate and responds quickly. Support the combined use of multi-way hydraulic lock and speed regulating valve to further improve the flexibility and control accuracy of the system.
- Double-acting function: Through the solenoid valve reversing, the oil cylinder can achieve bidirectional action to meet the needs of different application scenarios.
- Flexible motor configuration: The motor power range is 0.1-0.35KW, and the voltage is optional from 220-380V, which can adapt to a variety of application scenarios and power supply conditions.
- Additional functions: Support the combined use of multi-way hydraulic locks and speed regulating valves
- Application range: Widely used in various types of mechanical equipment, such as automated production lines, logistics equipment, construction machinery, etc.

The oil immersed double actina power unit is widely used in various occasions requiring efficient, quiet and stable hydraulic power due to its compact structure, low noise and high reliability. Specific applications include but are not limited to:

- Automated production line: Provide stable bidirectional power support to ensure smooth production process.
- Logistics equipment: such as forklifts, stackers, etc., to improve work efficiency and achieve precise control.
- Construction machinery: such as lifting platforms, excavators, etc., to enhance the reliability and durability of equipment and meet the needs of complex working conditions.

SPECIAL NOTES

The power unit is an S3 working system and can not operate continuously. It starts in 10 seconds and stops in 90 seconds.

Before installation, ensure that hydraulic components such as the oil cylinder, oil pipe, and joint are free of impurities.

The viscosity of hydraulic oil shall be 15 - 68st. No. 46 anti-wear hydraulic oil is recommended in summer, and No. 32 low-temperature hydraulic oil is recommended in winter.

After starting the operating system for the first time, check whether the oil in the oil tank is sufficient, generally 2/ 3 of the oil tank.

After the system is used for the first 100 hours, the hydraulic oil shall be replaced, and then the hydraulic oil shall be replaced every 3000 hours.

SCHEMATIC DIAGRAM

SPECIFICATIONS

Note: if you need system parameters such as pump, pressure, and motor power with different flow, please contact our salesman.
